H Series Front Wings
The H-SERIES High Aspect foil range is the latest offering from Cabrinha’s state of the art foil design program.
The H-series wings represent the pinnacle in hydrodynamic efficiency & performance while seamlessly integrates into the Cab Fusion Foil system.
The high aspect shape allows for effortless pumping, insane glide while retaining an ‘easy-to-steer’ feeling.
Whether you use them for wing, kite or foil-surfing, rise to the occasion with all of the H-series’ cutting edge features and be prepared for the endless ride…
DESIGN PROFILE
Swept outline, Ultra lean efficient profile, moderate anhedral
WING FEATURES
- Loose and agile feel for superior maneuverability
- Ultra lean profile for wide speed range
- Integrated fuselage with tapered fit
- Incredible torsional stiffness
- Full prepreg carbon construction
- PMI core for superior strength to weight ratio
- Moderate anhedral for a more efficient lift platform
TECH SPECS
- H650- 650cm², WS 720, AR 7.9, Chord 125mm
- H800- 800cm², WS 900, AR 9.9, Chord 125mm
- H1000- 1000cm², WS 900, AR 8.1, Chord 155mm
- H1200- 1200cm², WS 900, AR 6.7, Chord 185mm
H Series Rear Stabilizer
The HS180 High Aspect Stabilizer has been seamlessly molded as one single component into the fuselage to give exceptional efficiency and stiffness. This allows the rider complete control through varying degrees of the turn and has been precisely tuned for use with all H-series and X-series wings.
DESIGN PROFILE
Swept outline, ultra lean efficient profile and moderate anhedral
WING FEATURES
- Optimal efficiency and maneuverability
- Flat center, to downward tips, for perfect balance between locked-in feel and agility
- Single molded components for minimal drag
- Full prepreg carbon construction
- PMI core for superior strength to weight ratio
TECH SPECS
- 420mm, 180 cm², AR 9.8
Fusion Alloy Mast with Helicoil
HIGH PERFORMANCE – DURABILITY
SIZES: 40 / 70 / 90 CM MAST
The Fusion Alloy mast is constructed from extruded aircraft grade aluminum that result in an incredibly rigid & hydrodynamic structure. Helicoil inserts eliminate salt water corrosion around the screw connection points. It seamlessly integrates into all 9cm industry-standard foil boxes.
FEATURES
- Choice of fixed top plate or FQR (Foil Quick Release)
- 3-screw connection for superior rigidity
- Aircraft grade extruded, anodized 6061-T6 aluminum
- Precision tapered fuse-to-mast connection for optimal rigidity
- Helicoil inserts minimizes corrosion and provides long lasting durability
Fusion Hybrid Socket Plate Mount
